DESOLDER/PB FREE

DESOLDER
TOP-450・452・453
  • DESOLDERING MACHINE
  • LOW VOLTAGE 24V
  • DIGITAL DISPLY
TOP-450
  • HIGH POWER 80W
  • RESPONSE TO Pb free solder
  • HEATER TURBO
  • ESD
  • DIGITAL TYPE
  • For thermo control…TOP-450

CHOSEN DESOLDER FOR EVERY ENGINEER

TOP-452
DIAL TYPE
LOW COST, good performance…TOP-452
TOP-453
DIAL TYPE
Air type…TOP-453
  • ・NO SOLDER CLOG
  • ・ONE-TOUCH CLEANING
  • ・BIG POWER AND HEATER TURBO FUNCTION
  • ・AC 24V, LOW VOLTAGE HEATER
  • ・PID THERMO CONTROL
  • ・MULTI SAFETY DESIGN AND MAINTENANCE
MECHANICAL COMPONENTS
  1. NO SOLDER CLOG
    NO SOLDER CLOG
    • The tip is mode shorter than standard model. (60% length)
    • The tip pipe goes straight to a tank without joint part.
    • No air leaking and keeps suction maximum.
  2. BIG POWER AND HEATER TURBO FUNCTION
    • Big tip capacity, big heat capacity.
    • The heater is turned ON automatically when sucking to keep tip temperature continue for Pb free desoldering.
  3. PID THERMO CONTROL
    • Built in CA sensor in the solder tip.
    • The solder tip temperature is controlled with high response feed back zero cross SSR PID thermo controller to keep the solder tip temperature continue.
  4. ONE - TOUCH CLEANING
    ONE - TOUCH CLEANING
    • Easy to clean up the solder tank and change the filter.
    • Just only remove a cap.
    • No solder sticking special stainless steel cartridge filter.
  5. COMPARISON SOLDER TIP TEMPERATURE(Cooper plate0.5t×100×100)
    COMPARISON SOLDER TIP TEMPERATURE
    COMPARISON DATE
    Temperature decrease during SUCTION
    compared with conventional product
  6. THERMO CONTROL For SUPPORT ISO 9000
    • Temperature feed back under load by builting in CA sensor in the solder tip and digital display.
  7. NOISELESS CONTROL VACUUM PUMP AND HIGH RESPONSE
    • Equipped a zero cross SSR control noiseless vacuum pump and high response vacuum generator (700mmHg)type Top-453.
  8. 24 VOLT A.C. LOW VOLTAGE HEATER
    • Equipped 80 watts ceramic, heater drives at 24 volt.
    • High isolate resistance makes good effect for high density LSI, etc. to protect from destruction of IC.
Specifications

Please see here. (It opens in a new window. )

※Our company receive an Order. Your request power supply 115 220v the above All items

Our catalog will be promptly sent on your Request.
